    BTO-22 CBT-65 High Security Wire Fence , Prison Coiled Military Flat Barbed Wire

    Ask Lasest Price
    Brand Name : SS
    Certification : SGS
    Price : US $300-600 / Tons
    Payment Terms : L/C, T/T, Western Union
    Supply Ability : 1000 tons/ton per week
    Delivery Time : 10-15days after confirming the order
    • Product Details
    • Company Profile

    BTO-22 CBT-65 High Security Wire Fence , Prison Coiled Military Flat Barbed Wire

    Razor barbed wire, also called as the razor stinging, razor wire, is a new type of fence.

    Razor barbed wire with beautiful, economical and practical,good prevention effect,

    convenient construction and other excellent characteristics.

    It can be made into different crossed type in different diameter and widely used in high wall Or bounding wall, it has good effect on insulating and protecting.

    The normally size is as follows:


    Outside DiameterNo. of LoopsStandard Length per CoilTypeNotes
    450mm11217MBTO-10. 12.18.20.22concertina
    500mm10216MBTO-10. 12.18.20.22concertina
    600mm8614MBTO-10. 12.18.20.22concertina
    700mm7212MBTO-10. 12.18.20.22concertina
    800mm6410MBTO-10. 12.18.concertina
    960mm529MBTO-10. 12.18.20.22concertina
    Length, diameter can be made according to customers request.

    Outside DiameterNo.of LoopsStandard Length per CoilTypeNotes
    300mm334-5mCBT-60.65Single coil
    450mm337-8mCBT-60.65Single coil
    500mm5612-13mCBT-60.65Single coil
    700mm5613-14mCBT-60.65Single coil
    960mm5614-15mCBT-60.65Single coil
    450mm568-9m(3 clips)BTO-10.12.18.22.28.30Cross type
    600mm5610-11m(3 clips)BTO-10.12.18.22.28.30Cross type
    900mm5612-14m(5 clips)BTO-10.12.18.22.28.30Cross type
    980mm5614-16m(5 clips)BTO-10.12.18.22.28.30Cross typ
    Razor blade type and specification
    Reference Number

    Thickness

    (mm)

    Wire Dia

    (mm)

    Barb Length

    (mm)

    Barb Width

    (mm)

    Barb spacing

    (mm)

    BTO-120.5±0.052.5±0.112±115±126±1
    BTO-220.5±0.052.5±0.122±115±134±1
    BTO-300.5±0.052.5±0.130±118±145±1
    CBT-600.5±0.052.5±0.160±132±1100±1
    CBT-650.5±0.052.5±0.165±121±1100±1

    Material: high quality and low in carbon steel and stainless steel sheet

    Type: cross type razor barbed wire,single razor barbed wire,flat razor barbed wire,welded razor wire mesh.

    Features: excellent protective performance, beautiful, great variety, rapid construction, the deterrence effect.

    Usage: military border, prisons, defense agencies and facilities, important state facilities, residential, residential barrier protection.

    Packing: bulk,simple packing and carton packing.

    Simple packing: inside is water proof paper and outside is woven bags and

    then compression.

    Carton packing: razor mesh coils are loading into hard cartoon boxes.
